Problem:
On average, how many tosses of a fair coin does it take to see HTH?
This was honestly me for the past hour..
To solve this problem we start by defining our initial state $S_0$ as:
$$\begin{align*} S_0 &= P(H)[1 + S_H] + P(T)[1 + S_0] \quad \text{where } P(H) = P(T) = \frac{1}{2} \end{align*}$$
then from state $S_0$ we can define the following states:
$$\begin{align*} S_H &= P(H)[1 + S_H] + P(T)[1 + S_{HT}] \\ S_{HT} &= P(H)[1 + 0] + P(T)[1 + S_0] \end{align*}$$
The sequence HTH is determined by the state $S_{HT}$, if we roll tails we go back to state $S_0$. Now we want to convert these equations into standard form to solve for the unknowns.
Starting with $S_0$ we have:
$$\begin{align*} S_0 &= \frac{1}{2}[1 + S_H] + \frac{1}{2}[1 + S_0] \\ S_0 &= \frac{1}{2} + \frac{1}{2} S_H + \frac{1}{2} + \frac{1}{2} S_0 \\ S_0 &= 1 + \frac{1}{2} S_H + \frac{1}{2} S_0 \\ S_0 - \frac{1}{2} S_0 - \frac{1}{2} S_H &= 1 \\ \frac{1}{2} S_0 - \frac{1}{2} S_H &= 1 \\ \frac{1}{2} S_0 - \frac{1}{2} S_H + 0S_{HT} &= 1 \end{align*}$$
Then doing the same for $S_H$:
$$\begin{align*} S_H &= \frac{1}{2}[1 + S_H] + \frac{1}{2}[1 + S_{HT}]\\ S_H &= \frac{1}{2} + \frac{1}{2} S_H + \frac{1}{2} + \frac{1}{2} S_{HT} \\ S_H &= 1 + \frac{1}{2} S_H + \frac{1}{2} S_{HT} \\ S_H - \frac{1}{2} S_H - \frac{1}{2} S_{HT} &= 1 \\ \frac{1}{2} S_H - \frac{1}{2} S_{HT} &= 1 \\ 0S_0 + \frac{1}{2} S_H - \frac{1}{2} S_{HT} &= 1 \\ \end{align*}$$
And finally for $S_{HT}$:
$$\begin{align*} S_{HT} &= \frac{1}{2}[1 + 0] + \frac{1}{2}[1 + S_0] \\ S_{HT} &= \frac{1}{2} + \frac{1}{2} + \frac{1}{2}S_0 \\ S_{HT} &= 1 + \frac{1}{2}S_0 \\ -\frac{1}{2}S_0 + 0S_H + S_{HT} &= 1 \\ \end{align*}$$
If we set up our system of equations in matrix form we have:
$$\begin{align*} \begin{bmatrix} 0.5 & -0.5 & 0 \\ 0 & 0.5 & -0.5 \\ -0.5 & 0 & 1 \end{bmatrix} \begin{bmatrix} S_0 \\ S_H \\ S_{HT} \\ \end{bmatrix} = \begin{bmatrix} 1 \\ 1 \\ 1 \\ \end{bmatrix} \end{align*}$$
Ok to solve this we can use Gaussian elimination to solve for the unknowns, we can use NumPy specifically np.linalg.solve to do this but since the problem is easy enough we can do it manually.
import numpy as np
A = np.array([[0.5, -0.5, 0], [0, 0.5, -0.5], [-0.5, 0, 1]])
b = np.array([1, 1, 1])
matrix = np.column_stack((A, b))
matrix[0, :] = matrix[0, :] * 2
matrix[1, :] = matrix[1, :] * 2
matrix[-1, :] = matrix[-1, :] * 2
matrix[0, :] = matrix[0, :] + matrix[1, :]
matrix[1, :] = matrix[0, :] + matrix[1, :]
matrix[1, :] = matrix[-1, :] + matrix[1, :]
matrix[0, :] = matrix[0, :] * 2
matrix[0, :] = matrix[0, :] + matrix[-1, :]
matrix[-1, :] = matrix[0, :] + matrix[-1, :]
matrix[-1, :] = matrix[-1, :] * 1 / 2
print(matrix)
[[ 1. 0. 0. 10.]
[ 0. 1. 0. 8.]
[ 0. 0. 1. 6.]]
The final solution is 10 that is from $S_0$ on average it will take about 10 tosses to see HTH.
$$\begin{align*} \begin{bmatrix} 1 & 0 & 0 \\ 0 & 1 & 0 \\ 0 & 0 & 1 \end{bmatrix} \begin{bmatrix} S_0 \\ S_H \\ S_{HT} \\ \end{bmatrix} = \begin{bmatrix} 10 \\ 8 \\ 6 \\ \end{bmatrix} \end{align*}$$
